Dot is a simple pen machined from aluminum and anodized black.
![](https://s3images.coroflot.com/user_files/individual_files/473332__IeyEF0nqUPdvTjNmFYRG40ay.jpg)
I started this project by setting some goals that I wanted to achieve.
![](https://s3images.coroflot.com/user_files/individual_files/473332_WllpyssXVFOQZGBlnWm47HTNs.jpg)
I then began to prototype pen forms and the mechanism I would use to retract the ink cartridge.
![](https://s3images.coroflot.com/user_files/individual_files/473332_wv2YBVdUle5dQPQKaOuVzYU6d.jpg)
In CAD I developed the pen further and produce a technical drawing I could then machine from.
![](https://s3images.coroflot.com/user_files/individual_files/473332_nCpPOQfCum3JptcJAaucBfM9J.jpg)
![](https://s3images.coroflot.com/user_files/individual_files/473332_4B8mqsImQHqBPkv8KyfZymGU7.jpg)
I then machined the upper body, lower body, and a Delrin pin that holds the two halves together. After purchasing two set screws an ink cartridge and a spring I assembled my pen.
![](https://s3images.coroflot.com/user_files/individual_files/473332_0hlOl55AsZ08369YJzDRQrJOJ.jpg)
Photo of physical pen
![](https://s3images.coroflot.com/user_files/individual_files/473332_XmtVB5JB8a037Wtnk_ReTsKsn.jpg)
Photo of physical pen.
