Brian Tuley

The Saw Animator module is a very interesting module when you whish to get that FAT sound, usually obtained with two or more sawtooth VCOs, but you are short of VCOs. You can get this typical sound with only one sawtooth VCO, thanks to Bernie Hutchins (JAES, 1981). The Digisound 80 has this wonderful module and Scott Bernardi designed a version of its own. The present module is a somehow simplified but yet efficient version. To get the best of this module, it must be used in conjunction with a mixer. When used with a sawtooth LFO and inputing fixed CVs in the MOD inputs, one can achieve some interesting phase shifted modulators such as quadrature modulation.
